| CPU |
Intel® Socket LGA1700 for 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors* |
| Supports up to Intel® 65W CPU |
| Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0** |
| * Refer to www.asus.com for CPU support list. |
| ** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types. |
| Chipset |
Intel® H610 Chipset |
| Memory |
2 x DIMM, Max. 64GB, DDR4 3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory* |
| Dual Channel Memory Architecture |
| Supports Intel® Extreme Memory Profile (XMP) |
| *Actual Memory data rate depends on the CPU types and DRAM modules, for more information refer to www.asus.com for memory support list. |
| Graphics |
1 x D-Sub |
| 1 x HDMI® port** |
| * Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates. |
| ** Supports 4K@60Hz as specified in HDMI 2.1. |
| Expansion Slots |
Intel® 12th Gen Processors |
| 1 x PCIe 4.0 x 16 slot |
| Intel® H610 Chipset |
| 1 x PCIe 3.0 x 1 slot |
| Storage |
Total supports 1 x M.2 slot and 4 x SATA 6Gb/s ports |
| Intel® H610 Chipset |
| M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x 4 mode) |
| 4 x SATA 6Gb/s ports |
| Ethernet |
1 x Realtek 1Gb Ethernet |
| USB |
Rear USB (Total 6 ports) |
| 2 x USB 3.2 Gen 1 ports (2 x Type-A) |
| 4 x USB 2.0 ports (4 x Type-A) |
| Front USB (Total 4 ports) |
| 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports |
| 1 x USB 2.0 header supports additional 2 USB 2.0 ports |
| Audio |
Realtek 7.1 Surround Sound High Definition Audio CODEC*
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback |
| Audio Features |
| - Audio Shielding |
| - Premium audio capacitors |
| - Dedicated audio PCB layers |
| * A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output. |
| Back Panel I/O Ports |
2 x USB 3.2 Gen 1 ports (2 x Type-A) |
| 4 x USB 2.0 ports (4 x Type-A) |
| 1 x D-Sub port |
| 1 x HDMI® port |
| 1 x Realtek 1Gb Ethernet port |
| 3 x Audio jacks |
| 1 x PS/2 Keyboard (purple) port |
| 1 x PS/2 Mouse (green) port |
| Internal I/O Connectors |
Fan and Cooling related |
| 1 x 4-pin CPU Fan header |
| 1 x 4-pin Chassis Fan header |
| Power related |
| 1 x 24-pin Main Power connector |
| 1 x 4-pin +12V Power connector |
| Storage related |
| 1 x M.2 slot (Key M) |
| 4 x SATA 6Gb/s ports |
| USB |
| 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports |
| 1 x USB 2.0 header support additional 2 USB 2.0 ports |
| Miscellaneous |
| 1 x Clear CMOS header |
| 1 x Chassis Intrude header |
| 1 x COM Port header |
| 1 x Front Panel Audio header (AAFP) |
| 1 x LPT header |
| 1 x Speaker header |
| 1 x SPI TPM header (14-1 pin) |
| 1 x 10-1 pin System Panel header |
| Special Features |
ASUS 5X PROTECTION III |
| - DIGI+ VRM |
| - LANGuard |
| - Overvoltage Protection |
| - SafeSlot Core |
| - Stainless-Steel Back I/O |
| ASUS Q-Design |
| - Q-DIMM |
| - Q-Slot |
| ASUS Thermal Solution |
| - Aluminum heatsink design |
| Luminous anti-moisture coating |
| USBGuard |
| Software Features |
ASUS Exclusive Software |
| Armoury Crate |
| AI Suite 3 |
| - Performance And Power Saving Utility |
| TurboV EVO |
| EPU |
| DIGI+ VRM |
| ASUS CPU-Z |
| Norton Anti-virus software (Free Trial version) |
| WinRAR |
| UEFI BIOS |
| ASUS EZ DIY |
| - ASUS CrashFree BIOS 3 |
| - ASUS EZ Flash 3 |
| - ASUS UEFI BIOS EZ Mode |
| BIOS |
128 Mb Flash ROM, UEFI AMI BIOS |
| Manageability |
WOL by PME, PXE |
| Accessories |
Cables |
| 2 x SATA 6Gb/s cables |
| Miscellaneous |
| 1 x I/O Shield |
| 1 x M.2 ANCHOR |
| Installation Media |
| 1 x Support DVD |
| Documentation |
| 1 x User guide |
| Operating System |
Windows® 11 64-bit, Windows® 10 64-bit |
| Form Factor |
mATX Form Factor |
| 8.9 inch x 7.6 inch (22.6 cm x 19.3 cm) |
